Fully Automatic Hard Candy Production Line PLC / Computer Process Control

  • Fully Automatic Hard Candy Production Line PLC / Computer Process Control
  • Fully Automatic Hard Candy Production Line PLC / Computer Process Control
Place of Origin Jiangsu, China (Mainland)
Brand Name Haitel
Certification CE ISO9001
Model Number HTL
Minimum Order Quantity 1 piece
Price Negotiable
Packaging Details Wooden case packing according to your demand
Delivery Time Shipped in 45 work days after payment
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 15 Piece/Pieces per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Voltage 380V Power 18KW
Weight 3500KG Dimension 15000*1200*2100mm
Certification CE, ISO9001：2008 Warranty 1 Year
Highlight

candy manufacturing machine

,

hard candy making equipment
Leave a Message
Product Description



Fully Automatic Hard Candy Production Line of factory



The strong point of the hard candy/dragee line is as following:

1. PLC /computer process control available;
2.An LED touch panel for easy operating;
3.The standard production capacity from 150 kgs/h to 450kgs/h;

4.Optional (mass) flowing controlled by Frequency inverters ;
5.Inline injection, dosing and premixing techniques for the proportional addition of liquid(milk); Dosing pumps for the automatic injection of colors, flavors and acids;
6.One set of extra chocolate paste injection system for making chocolatecentral candies; "two/threecolor striped depositing","two or three color double layers depositing", "central filling", "clear" hard candies and etc. can be made.
7.Moulds can be made according to the candies samples provided by the customer."

Specifications:

This machine can produce hard candy, 2 color candy, fruit candy, butter scotch,etc..



TECHNICAL SPECIFICATIONS:

Model HTL-150 HTL-300 HTL-450 HTL-600
Output(kg/h) 150 300 450 600
Max candy weight 6g 6g 6g 6g
speed 55~65 n/min 55~65 n/min 55~65 n/min 55~65 n/min

Steam consumption

Steam pressure

 250kg/h, 0.5~0.8MPa 300kg/h, 0.5~0.8MPa 400kg/h, 0.5~0.8MPa 500kg/h, 0.5~0.8MPa

Compressed air consumption

Compressed air pressure

0.2m3/min,

0.4~0.6MPa

0.2m3/min,

0.4~0.6MPa

0.25m3/min,

0.4~0.6MPa

0.25m3/min,

0.4~0.6MPa
Electric power needed 18kW/380V 27kW/380V 34kW/380V 42kW/380V
Total length(m) 15 17 17 20
Gross weight 3500kg 4000 kg 4500 kg 5000 kg



Fully Automatic Hard Candy Production Line PLC / Computer Process Control 0

Fully Automatic Hard Candy Production Line PLC / Computer Process Control 1Fully Automatic Hard Candy Production Line PLC / Computer Process Control 2
